Product Description:

This is a multi-function CCTV IP&HD tester monitor, which can resolve project problems and make the installation process quicker and more efficient. It is developed for the installation and maintenance of video monitoring system. Utilizing a visual and functional OSD menu, it support IP camera, Standard 960H Camera and coaxial HD 4.0 8MP TVI/ AHD/ CVI camera test, coaxial view control and menu debugging. Support preview, zoom, photograph, play back. Its functions, easy operation, and convenient portability enable it simple for the contractor to install and maintain the video camera, promote working efficiency and cost-down the expenditure of the project.

Features:

✔ 7 inch 1920*1200 resolution retina display touch screen IP & CVBS & TVI & AHD & CVI tester.

✔ Compatible with almost all models' IP cameras, such as Hikvision, DaHua, uniview, Hanbon, Samsung.

✔ Support coaxial HD 4.0 8MP TVI/ AHD/ CVI camera test, coaxial view control and menu debugging. Support preview, zoom, photograph, play back.

✔ Support TDR cable test. To test cable status, length, attenuation, reflect rate, impedance, time delay deviation etc.

✔ Built-in WIFI, Support wireless WIFI hotspots.10/100M Lan Port, H.265/H.264, 4K video display via mainstream.

✔ PoE DC48V power output, Max power 24W; Support 12V /3A DC power output, 5V/2A power output.

✔ Support ONE SCREEN TWO WINDOWS DISPLAYS. IP camera and analog camera pictures can be shown at the same time.

✔ Support quick screen capture function, press and hold confirm key to get screen shot

✔ BUILT IN IP SCANNING APP, auto-scan the whole network segment IP, and auto-modify tester’s IP address

✔ HDMI signal output 3840*2160P, support 1080p display image, record and snapshot

✔ UTP cable, telephone cable's sequence and connectivity test.

✔ POE/DC12V voltage and power measurement

✔ Lithium Ion Polymer 7.6V/7500mAh Battery, working time lasts 11 hours, Support Smart Charge, Battery charge time 2.5 hours

What's in the Box?

1 x IP Camera Tester
1 x Power Output Cable
1 x RS485 Test Cable
1 x Audio Test Cable
1 x BNC Cable
1 x Crocodile Clip BNC Cable
1 x Cable Tracer
1 x Power Adaptor
1 x Screw Driver
3 x Straps
1 x Storage Bag
1 x Built-in English User Manual

Why do I need a security-grade monitor?

There’s a big difference between professional security-grade monitors and standard consumer-grade displays.
You may think that a standard consumer-grade LCD monitor is acceptable for video security applications and will save you money. However, while they do cost less, they are not designed to meet the rigorous demands of security applications and can quickly burn out with continuous use.

Advantages of security-grade monitor:

1. Designed for Continuous Use with proper ventilation and burn-in prevention

2. Mounting Flexibility

3. Multiple Connections for Security Applications

4. Better Warranty Coverage

Much More Benefits for Surveillance Applications. Security-grade surveillance monitors are specifically designed to provides a cost-effective solution that’s built to last and offers the reliability, flexibility and performance needed for continuous surveillance applications.
