Flir Digimerge Dnr114p0 Hd 4 Ch Security System
Nvr 1tb Hdd
USD $132.99
Condition : Open box
Free Shipping
{{variant_type_name}} :
Notify me when the price drops
We will email you if we find a lower price on this product!
LOREX AND FLIR NETWORK CAMERAS ONLY. STORE DISPLAY, MINOR SCRATCHES OR SCUFFS POSSIBLE, 4 CHANNEL FLIR DNR114P0 DVR SYSTEM. SUPPORTS LOREX AND FLIR 720P AND 1080P NETWORK CAMERAS. WILL NOT WORK WITH ANY OTHER BRAND OF CAMERA . FULLY TESTED AND RESET TO DEFAULT PASSWORD AND SETTINGS. 1TB HARD DRIVE IS INCLUDED. NO CAMERAS ARE INCLUDED. IF YOU NEED CAMERAS PLEASE CHECK OUT OUR STORE OR MESSAGE US.” EXACT ITEM PICTURED IN CONDITION PICTURED. NVR COMES WITH POWER CABLE, NETWORK CABLE, MOUSE AND HDMI CABLE.
Higher Capacity ProcessingReal-time recording in Full HD on each channel
SystemOperating SystemEmbedded LINUXPentaplexSimultaneous View, Record, Playback, Backup, and Remote MonitoringNumber of Channels4/8 ChannelInputs/OutputsVideo IN4 ch: 4 PoE Video Input / 8 ch: 8 PoE Video InputVideo OUTYesVGA OUTYesHDMIYesAudio IN1 Line IN (RCA) for two-way audioAudio OUT1 Line OUT (RCA) for two-way audioUSB Port4ch: 2 at the back
8ch: 1 at the back, 1 at the frontAlarm INNoAlarm OUTNoVideo Output Resolution1920×1080, 1280×1024, 1280×720, 1024×768PTZ controlFLIR IP PTZ cameras onlyDisplayLive Display4ch: 1, 4 / 8ch: 1, 4, 8Live Display Speed4ch: 120 NTSC, 100 PAL / 8ch: 240 NTSC, 200 PALOSDON/OFFSystem NavigationUSB MouseMotion Area SettingAdjustable grid (22x18)Sensitivity levels100Firmware UpgradeAutomatic over the Internet & via USB device and networkUser AuthorityBy user groupTime SynchronizationAuto time sync by NTP serverRecordingVideo CompressionH.264Audio CompressionG.711Resolution720P (1280x720), 1080P (1920x1080),
3MP (2028x1536), 5MP (2560x1920)Record RateNTSC: 4ch: 120FPS @ 720P / 1080P / 3MP / 5MP
8ch: 240FPS @ 720P / 1080P / 3MP / 5MP
PAL: 4ch: 100FPS @ 720P / 1080P / 3MP / 5MP
8ch: 200FPS @ 720P / 1080P / 3MP / 5MPRecord Resolution SettingPer camera for different resolutionsRecording Quality Control6 LevelsRecord ScheduleBy hour, by day, by recording mode, by motion, by channelPre RecordingMax. 30 SecondsPost RecordingMax. 5 MinutesReliabilityWatch-Dog, auto-recovery after power failureCovert VideoYesPlayback and BackupPlayback Channel4ch / 8ch: 1 / 4Playback SpeedVariable Max 16xPlayback PlayersBackup PlayerSearchBy time & eventLog SearchUp to 1,000 lines for motion detected, configuration changes, connects/disconnects and video lossAudio PlayYes (audio camera required)Storage & ArchiveStorage4/8 ch: Up to 1 HDD (SATA)Maximum Capacity4/8 ch: Up to 1 x 4TBBackup MediaUSB flash drive, HDD, & NetworkBackup File FormatDAV or ASF fileConnectivityCloud ConnectionFLIR Cloud™Supported Operating SystemsWindows™, Mac OSRemote SoftwareClient Software (PC/Mac)Email NotificationText with snapshotInstant Smart Phone & Tablet SupportiPad®, iPhone®, Android™DDNSFLIR DDNSSystem ConfigurationFull setup configuration over networkPortsProgrammable by userNetwork ProtocolHTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP FilterNetwork Interface10/100–Base-TX, RJ-45Network Bit Rate80Mbs total
48~8192kbps per cameraIP Cameras SupportedFLIRNVR General InformationPower Consumption4ch: 10 watts (No HDD Installed)
8ch: 12 watts (No HDD Installed)Supply Voltage4ch: 100VAC-240VAC, 48V DC, 1.5A, 50/60Hz
8ch: 100VAC-240VAC, 48V DC, 2A, 50/60HzTotal PoE Power Output
(across all channels)4ch: 50W (Max 25W per Camera)
8ch: 120W (Max 25W per Camera)Unit Weight4ch:: 1.1lbs / 0.5kg (without HDD)
8ch:: 1.5lbs / 0.7kg (without HDD)Dimensions (W x H x D)4ch: 8.1 x 1.8 x 8.1” / 205 x 45 x 205mm
8ch: 10.6 x 1.8 x 8.1” / 270 x 45 x 205mmOperating Temperature14° ~ 131° F / –10° ~ 55° CHumidity10 ~ 90% NC
Higher Capacity ProcessingReal-time recording in Full HD on each channel
- Supports HD recording with cameras up to 5MP
- Pentaplex operation - simultaneous View, Record, Playback, Backup & Remote Monitoring
- 80Mbps network bit rate processing
- 4/8 integrated PoE ports
- 50 Watt total PoE (up to 25W per channel)
- Auto-discovery of FLIR IP Cameras with no programming
- Supports SATA HDD up to 4TB
- Back-up via 2x USB 2.0 ports
- Set up remote viewing in three easy steps: install FLIR Cloud app, scan QR code on DVR, view live video
- Multisite viewing on FLIR Cloud CMS for PC / Mac
SystemOperating SystemEmbedded LINUXPentaplexSimultaneous View, Record, Playback, Backup, and Remote MonitoringNumber of Channels4/8 ChannelInputs/OutputsVideo IN4 ch: 4 PoE Video Input / 8 ch: 8 PoE Video InputVideo OUTYesVGA OUTYesHDMIYesAudio IN1 Line IN (RCA) for two-way audioAudio OUT1 Line OUT (RCA) for two-way audioUSB Port4ch: 2 at the back
8ch: 1 at the back, 1 at the frontAlarm INNoAlarm OUTNoVideo Output Resolution1920×1080, 1280×1024, 1280×720, 1024×768PTZ controlFLIR IP PTZ cameras onlyDisplayLive Display4ch: 1, 4 / 8ch: 1, 4, 8Live Display Speed4ch: 120 NTSC, 100 PAL / 8ch: 240 NTSC, 200 PALOSDON/OFFSystem NavigationUSB MouseMotion Area SettingAdjustable grid (22x18)Sensitivity levels100Firmware UpgradeAutomatic over the Internet & via USB device and networkUser AuthorityBy user groupTime SynchronizationAuto time sync by NTP serverRecordingVideo CompressionH.264Audio CompressionG.711Resolution720P (1280x720), 1080P (1920x1080),
3MP (2028x1536), 5MP (2560x1920)Record RateNTSC: 4ch: 120FPS @ 720P / 1080P / 3MP / 5MP
8ch: 240FPS @ 720P / 1080P / 3MP / 5MP
PAL: 4ch: 100FPS @ 720P / 1080P / 3MP / 5MP
8ch: 200FPS @ 720P / 1080P / 3MP / 5MPRecord Resolution SettingPer camera for different resolutionsRecording Quality Control6 LevelsRecord ScheduleBy hour, by day, by recording mode, by motion, by channelPre RecordingMax. 30 SecondsPost RecordingMax. 5 MinutesReliabilityWatch-Dog, auto-recovery after power failureCovert VideoYesPlayback and BackupPlayback Channel4ch / 8ch: 1 / 4Playback SpeedVariable Max 16xPlayback PlayersBackup PlayerSearchBy time & eventLog SearchUp to 1,000 lines for motion detected, configuration changes, connects/disconnects and video lossAudio PlayYes (audio camera required)Storage & ArchiveStorage4/8 ch: Up to 1 HDD (SATA)Maximum Capacity4/8 ch: Up to 1 x 4TBBackup MediaUSB flash drive, HDD, & NetworkBackup File FormatDAV or ASF fileConnectivityCloud ConnectionFLIR Cloud™Supported Operating SystemsWindows™, Mac OSRemote SoftwareClient Software (PC/Mac)Email NotificationText with snapshotInstant Smart Phone & Tablet SupportiPad®, iPhone®, Android™DDNSFLIR DDNSSystem ConfigurationFull setup configuration over networkPortsProgrammable by userNetwork ProtocolHTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP FilterNetwork Interface10/100–Base-TX, RJ-45Network Bit Rate80Mbs total
48~8192kbps per cameraIP Cameras SupportedFLIRNVR General InformationPower Consumption4ch: 10 watts (No HDD Installed)
8ch: 12 watts (No HDD Installed)Supply Voltage4ch: 100VAC-240VAC, 48V DC, 1.5A, 50/60Hz
8ch: 100VAC-240VAC, 48V DC, 2A, 50/60HzTotal PoE Power Output
(across all channels)4ch: 50W (Max 25W per Camera)
8ch: 120W (Max 25W per Camera)Unit Weight4ch:: 1.1lbs / 0.5kg (without HDD)
8ch:: 1.5lbs / 0.7kg (without HDD)Dimensions (W x H x D)4ch: 8.1 x 1.8 x 8.1” / 205 x 45 x 205mm
8ch: 10.6 x 1.8 x 8.1” / 270 x 45 x 205mmOperating Temperature14° ~ 131° F / –10° ~ 55° CHumidity10 ~ 90% NC
