Hikvision 4k 16ch Cctv Ip Security Camera System

· Day/Night(ICR), Ultra DNR · Max. 25fps 1080P · H.265/H.264 dual-stream media server · Compatibility: HIKVISION,ONVIF，RTSP · Multi web browser, PC Client, mobile APP remote access · Support PoE · IP66 waterproof · built-in MIC
Hikvision 4K 16CH CCTV IP Security Camera System PoE 8MP ColorVu Audio 3.6mm lot ★Tips 🌷 APP Available : Hik-connect, Guard viewer, IVS-4200 🌷 Search Tool: SADP (search device and change IP address) 🌷 Default IP : 192.168.1.64 🌷 Camera lens: 2.8mm > NVR is 100% Original Hikvision, Support upgrade by Hikvision Official Website! > IP Camera is NOT Hikvision brand model but can be plug &play with Hikvision NVR . Item Feature 2MP Model PG2T27C 5MP Model PG2T57C 8MP Model PG2T87C 1/2.7" SONY CMOS Sensor 1/2.8" SONY CMOS Sensor 1/2.8" Sony Ultra CMOS Sensor · Day/Night(ICR), Ultra DNR · Max. 25fps 1080P · H.265/H.264 dual-stream media server · Compatibility: HIKVISION,ONVIF，RTSP · Multi web browser, PC Client, mobile APP remote access · Support PoE · IP66 waterproof · built-in MIC · Day/Night(ICR), Ultra DNR · MAX. 15fps 5MP(2592 × 1944),25fps 4MP(2560x1440)25fps 3MP · H.265/H.264 dual-stream media server · Compatibility: HIKVISION,ONVIF，RTSP · Multi web browser, PC Client, mobile APP remote access · Support PoE · IP66 waterproof · built-in MIC · Day/Night(ICR), Ultra DNR · Max. 20fps 8MP/25fps 6MP · H.265/H.264 dual-stream media server · Compatibility: HIKVISION,ONVIF，RTSP · Multi web browser, PC Client, mobile APP remote access · Support PoE · IP66waterproof · built-in MIC Embedded Plug & Play 16CH 1U 16POE 12MP NVR DS-7616NI-K2/16P ❃ Third-party network cameras supported ❃ Up to 12 Megapixels resolution recording ❃ Support 1-ch HDMI, 1-ch VGA, HMDI at up to 4K(3840x2160) resolution ❃ 16-ch network cameras can be connected with 160M incoming bandwidth ❃ Up to 2 SATA interfaces ❃ Plug & Play with up to 16 independent PoE network interfaces ❃ Support dual-os to ensure high reliablility of system running ❃ Support various VCA detection alarm and VCA search ❃ Support H.265/H.264/MPEG4 video formats Item Details Camera PG2TX7C Image Sensor 2MP:1/2.7" Sony COMS Sensor ; 5MP:1/2.8" Sony CMOS Sensor ;8MP:1/2.8" Sony Ultra CMOS Sensor Min. Illumination F1.0 24/7 full time color White Balance Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp Gain Auto/Manual Shutter Time 50Hz: 1/25 s to 1/100,000 s Day & Night ColorVu Privacy Mask 4 programmable privacy masks Lens Focal Length 3.6 mm (6mm Optional)Horizontal field of view: 130° Field of View Vertical field of view: 69° Diagonal field of view: 110° Compression Standard Video Compression Main Stream: H.265/H.264 Sub-stream: H.265/H.264/MJPEG H.264 Type Baseline profile/main profile/high profile Event Basic Event Motion Detection IR IR Distance Warm white LEDs, up to 50m IR LED 4PCS Image Max. Resolution 2MP:1920× 1080;5MP:2592 × 1944;8MP:3840 x 2160 Main Stream 2MP:25fps 2MP(1920x1080)/720P; 5MP:15fps 5MP(2592 × 1944),25fps 4MP(2560x1440)25fps 3MP/2MP/720P;8MP:20fps 8MP(3840 x 2160,25fps 6MP(3072x2048)30fps 5MP/4MP/3MP/2MP/720P Sub-Stream 2MP:D1/VGA/640x360/CIF 30fps, etc;5MP:D1/VGA/640x360/CIF 25fps, etc;8MP:VGA/640x360/480X360P/CIF 25fps, etc Image Enhancement 3D DNR, EIS, Regional Exposure, Privacy Mask, Mirror Network Ethernet RJ-45 (10/100Base-T) Protocols IPv4/IPv6, HTTP/RTSP/FTP/NFS/SMTP/DHCP/NTP/TCP/IP, etc. API ONVIF (Profile S, Profile G, Profile T),HIKVISION Simultaneous Live View Up to 20 channels Client SADP, Danale, Blue Iris , ISpy Web Browser IE 8 to 11,Chrome 31.0+, Firefox 30.0+, Edge 16.16299+ Interface Network Interface 1 RJ45 10 M/100 M Ethernet, PoE Power 12 VDC or POE General Language (Web Browser Access ) 7 languages:Chinese, English, Russian, German, Italian, , Turkish, 한국어 Power 12 VDC, 1.5 A (Max. 10.9 W, including Max. 4.2 W for IR);PoE (802.3af), 36 to 57 VDC, 0.35 A (Max. 12.2 W, including max. 4.2 W for IR) Working Environment Temperature: -20°C to 60°C (-4°F to 140°F), humidity: ≤ 90% Protection Level IP66 standard Material Aluminum alloy Dimension Φ 260mm × 140mm x 130mm Weight Approx. 0.9 kg (1.99 lb.) NVR: DS-7608NI-K2/8P
Video Parameter
Decoding capability8*1080P
Video and Audio
IP Video Input16-ch
Incoming Bandwidth160 Mbps
Outgoing Bandwidth160 Mbps
HDMI Output4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
VGA Output1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
Video Output ModeHDMI/VGA independent output
Audio Input1-ch, RCA (2.0 Vp-p, 1 KΩ)
Audio Output1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
Decoding
Decoding FormatH.265/H.265+/H.264/H.264+
Recording Resolution12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Synchronous Playback16-ch
Decoding Capability1-ch@12 MP (30 fps)/2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)/8-ch@1080p (30 fps)
Stream TypeVideo, Video & Audio
Audio CompressionG.711ulaw/G.711alaw/G.722/G.726
Network
Remote Connection128-ch
Network ProtocolTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Network Interface1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
PoE
Interface16, RJ-45 10/100 Mbps self-adaptive Ethernet interface
Power≤ 200 W
StandardIEEE 802.3 af/at
Auxiliary Interface
SATA2 SATA interfaces
CapacityUp to 10 TB capacity for each HDD
USB InterfaceFront panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0
Alarm In/Out4/1
General
Power Supply100 to 240 VAC, 50 to 60Hz
Consumption≤ 15 W (without HDD and PoE off)
Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
Working Humidity10 to 90 %
Dimension (W × D × H)385 × 315× 52 mm (15.2" × 12.4" × 2.0")
Weight≤ 3 kg (without HDD, 6.6 lb.)
Certification
FCCPart 15 Subpart B, ANSI C63.4-2014
CEEN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017 Payment Shipping Policy Return and Warranry About us Contact us Payment 1. Welcome to my store, I am selling all kinds of surveillance products, please choose what you need.
